LD SYSTEMS DAVE 12 G3 Active PA-System 540W
€699.00
Out of stock
Description
DAVE 12 G3 Active PA-System 540W
The new LD Systems DAVE 12 G3 is the perfect active PA system for high-powered live gigs, multimedia presentations, and permanent installations in bars and clubs. A 12″ bass reflex subwoofer and the satellites with 6.5″ drivers and HF horns ensure a good sound with driving, defined bass, natural mids, and clear treble. The 2.1 power amp stage is built into the subwoofer and provides the system components with 2000 W Peak power.
Specifications
| Product number: | LDDAVE12G3 |
|---|---|
| Product type: | PA Complete Systems |
| Colour: | Black |
| Max. SPL (continuous): | 119dB |
| Max. SPL (peak): | 130dB |
| Frequency response: | 40 – 19000Hz |
| Dispersion (H x V): | 90 x 40° |
| Weight: | 48,5kg |
| Subwoofer | |
| Low/mid driver dimensions: | 12″ |
| Woofer size: | 304.8mm |
| Woofer magnet: | Ferrite |
| Woofer brand: | Custom-made |
| Woofer voice coil: | 2.5″ |
| Woofer voice coil (mm): | 63.5mm |
| Cabinet construction: | vented |
| Cabinet material: | 15 mm Plywood |
| Cabinet surface: | texture paint |
| Subwoofer width: | 435mm |
| Subwoofer height: | 500mm |
| Subwoofer depth: | 540mm |
| Subwoofer features: | LD Systems “Evolutive” handles, threaded flange M20 |
| Mid/Hi System | |
| Midrange size: | 6.5″ |
| Midrange size: | 165.1mm |
| Midrange magnet: | Ferrite |
| Midrange brand: | Custom-made |
| Midrange voice coil: | 1.75″ |
| Midrange voice coil: | 44.5mm |
| Horn: | CD horn |
| Tweeter dimensions: | 1″ |
| Tweeter dimensions (mm): | 25.4mm |
| Tweeter magnet: | Ferrite |
| Tweeter brand: | Custom-made |
| Tweeter voice coil: | 1″ |
| Tweeter voice coil (mm): | 25.4mm |
| Mid/Hi system impedance: | 4Ohm(s) |
| Loudspeaker inputs: | 1 |
| Speaker input connections: | Speakon compatible |
| Cabinet construction mid/high: | Closed |
| Mid/Hi system cabinet material: | 15 mm Plywood |
| Mid/Hi system cabinet surface: | texture paint |
| Mid/Hi system width: | 250mm |
| Mid/Hi system height: | 400mm |
| Mid/Hi system depth: | 250mm |
| Mid/Hi system features: | SM707 stand mount 36 mm, ergonomically shaped insert handles |
| Amplifier module (integrated in subwoofer) | |
| Amplifier: | Class A/B |
| Amplifier output system (RMS): | 500W |
| Amplifier output system (peak): | 2000W |
| Protection circuits: | limiter, overload, short circuit |
| Cooling: | volume-controlled fan |
| Controls: | Sub level, Subwoofer Phase Reverse, volume, Power |
| Indicators: | Limit, Signal, Protect (protection circuit engaged), on/off |
| Operating voltage: | transformer, 220 V AC – 240 V AC |
| Line inputs: | 2 |
| Line input connectors: | RCA, 6.3 mm jack, XLR |
| Line output connectors: | XLR |
| Loudspeaker outputs: | 2 |
| Speaker output connections: | Speakon compatible |
| Internal sampling frequency: | 1000kHz |
Additional information
| Weight | 32 kg |
|---|---|
| Brand |
