LD SYSTEMS GT10A Power Speaker 800W 10″
€365.00
In stock
Description
LD SYSTEMS GT10A Power Speaker 800W 10″
Loaded with a custom 10″ woofer and 1″ Celestion compression driver the GT 10 A active fullrange loudspeaker provides exceptional value and crisp, well balanced audio with a 65 Hz – 19 kHz frequency response, 90° x 60° dispersion and 119dB peak SPL.
The sturdy bass reflex cabinet is made from 15mm MDF and covered in heavy-duty textured Dura-Vinyl for protection and lasting appearance. It features a honeycomb steel grille, 54° monitor angle and dual tilt stand mount.
The GT 10 A is powered by a built-in Class D digital amplifier with high efficiency SMPS and 800 watts peak output. It provides line and microphone inputs on XLR and 6.3 mm connectors, a 2-band EQ and is protected against overcurrent and overvoltage for reliable operation.
A protective cover is available as accessory.
Specifications
| Product number: | LDGT10A |
|---|---|
| Product type: | PA loudspeaker |
| Type: | Actives |
| Low/mid driver dimensions: | 10″ |
| Woofer size: | 254mm |
| Woofer magnet: | Ferrite |
| Woofer brand: | Custom-made |
| Woofer voice coil: | 2″ |
| Woofer voice coil (mm): | 50.8mm |
| Horn: | CD horn |
| HF driver dimensions: | 1″ |
| HF Driver Size: | 25.4mm |
| HF driver magnet: | Ferrite |
| HF driver brand: | Celestion |
| HF driver voice coil: | 1″ |
| HF Driver Voice Coil: | 25.4mm |
| Amplifier: | Class D |
| Dispersion (H x V): | 90 x 60° |
| RMS: | 200W |
| Peak power: | 800W |
| Frequency response: | 65 – 19000Hz |
| Crossover frequency: | 2500Hz |
| Max. SPL (continuous): | 116dB |
| Max. SPL (peak): | 119dB |
| Protection circuits: | HF Driver, over voltage, over-current |
| Input sensitivity: | Mic: 150 mV / Line: -10dBu |
| Controls: | Line Gain, volume, Treble, Power, Mic Gain, Bass |
| Indicators: | Protect (protection circuit engaged), Signal, Power, Limit |
| Line inputs: | 1 |
| Line input connectors: | 6.3 mm jack, XLR |
| Mic inputs: | 1, 6.3 mm jack, XLR |
| Line outputs: | 1 |
| Line output connectors: | XLR |
| Operating voltage: | Switching power supply, 220 V AC – 240 V AC (Auto), 50 – 60 Hz, 110 V AC – 120 V AC |
| Cabinet material: | 15 mm MDF |
| Cabinet surface: | Dura-vinyl textured paint |
| Cabinet construction: | vented |
| Monitor angle: | 54° |
| Width: | 328mm |
| Height: | 500mm |
| Depth: | 293mm |
| Features: | dual-tilt flange (0°/5°), rugged steel grille |
| Weight: | 13,8kg |
Additional information
| Weight | 13.8 kg |
|---|---|
| Brand |
