Lewitt LCT 640 TS Condenser Microphone

Description

Lewitt LCT 640 TS Condenser Microphone

Designed and engineered in Austria, the LCT 640 TS will revolutionize the way we think about the recording process. Since the signal of the front and back diaphragm is provided by independent circuitries, any kind of polar pattern can be realized dynamically – even after the recording.

Specifications

• Tipe: Condenser, Externally Polarized
• Acoustical operating principle: Pressure gradient transducer
• Diaphragm: 3 micron gold sputtered Mylar
• Transducer Ø: 25.4 mm, 1 in
• Polar pattern (Dual Output Mode): Create any polar pattern in post-production
• Polar pattern (Multi-Pattern Mode): omni, wide cardioid, cardioid, supercardioid, figure-8
• Sensitivity: 31.4 mV/Pa, -30.1 dBV/Pa (cardioid) – – 30.3 mV/Pa, -30.3 dBV/Pa (omni) – – 34.1 mV/Pa, -29.4 dBV/Pa (figure-8)
• Equivalent noise level: 10 dB (A), cardioid
• Max. SPL for 0.5 % THD: 134 dBSPL, 0 dB pre-attenuation
• Signal / noise ratio: 84 dB (A)
• Dynamic range: 124 dB (A)
• Pre-attenuation pad: -0 dB,-6 dB,-12 dB,-18 dB
• Low-cut filter linear: 40 Hz (12 dB/oct) – – 80 Hz (12 dB/oct) – – 160 Hz (6 dB/oct)
• Internal impedance: 110 Ω
• Rated load impedance: 1,000 Ω
• Supply voltage: 48 V ± 4 V
• Current consumption: 5.1 mA
• Mic enclosure: Zinc die cast
• Connector: Gold plated 3-pin XLR + Mini 3-pin XLR
• Microphone dimensions: 158 x 52 x 36 mm, 6.22 x 2.04 x 1.42 in
• Microphone net weight: 425 g, 14.9  oz
