SOUNDSATION PMX-4MKII 6-Ch Powered Mixer & Effects MP3 Player
PMX-4 MKII is designed to be a powerful resource for live and educational purposes. The friendly user interface is one of the best features of this product and allows you to configure your sound device in a fast and easy way.The 6-Channel Active Mixer lets you plug microphones, instruments or any other audio equipment thanks to the XLR inputs on CH1-4, the ¼” Jack inputs on CH1-3, the stereo RCA inputs on CH4 and the 3mm jack input on Ch5/6 that allows you to plug a computer, a smartphone, a portable MP3 player etc.
Specifications
6-Channel 200+200W powered mixer with effect and multimedia player |
4 Mic/Line channel (CH1-4) with independent 2-band EQ and FX send bus with adjustable level |
1 stereo channel (CH5-6) with 3mm Jack connector for tablets, computers and other multimedia devices |
3-Band EQ on Master outputs |
24bit digital Reverb/Delay with Level, Delay Time and Repeat adjustment |
RCA Stereo TAPE In/Out for an external recorder/player |
MP3 player with A-Type USB and SD-Card slot for 8GB max mass storage devices |
200+200W @ 4ohm amplification |
System Type | Active Mixer with MP3 Player |
Rated Power | 100+100W @ 4ohm |
Peak Power | 200+200W @ 4ohm |
Frequency Range | 20Hz – 20KHz +1/-3dB @ 1W Output to 8ohm speakers |
Mixer | 6-Channel Inputs (4 x Mono /Line, 1 x Stereo Line) |
Input Impedance | Mic – 2Kohm (balanced) / 1kohm (unbalanced); Line – 10kohm; Tape IN – 47Kohm |
Input Channel EQ | HIGH +/-15dB @ 12kHz; LOW +/-15dB @ 80Hz |
3-Band EQ | Bass – Mid- Treble for Master Section |
Stereo Monitor Out | 1/4” Jack (TRS) |
Speaker Outputs | 2x 1/4” Jack mono |
DSP | 24-bit Delay/Reverb with Adjustable Level, Time and Repeat |
Digital Delay | Time 140 – 342ms |
Digital Player | USB A-Type (max 8Gb); SSD slot (max 8Gb) |
AC Input | 230 V – 50Hz |
Fuse | T2A 250V |
Dimensions (WxHxD) | 475x120x227mm – 18.70×4.74×8.94in |
Weight | 7.2 Kg – 18.87 lbs. |
